C34 for TSM Closed Loop Stepper Drive

OVERVIEW
This board interface is used for the connection between C82, C76, M16D, C35S y C62
and TSM23S Closed Loop Stepper.

FEATURES

• CONN 28 POS connector for Connection of Driver.

• RJ45 Connector for Axis.

• Encoder Output.

• Select Jumper for Hard Enable or Soft Enable.

• Select Jumper alarm active Low or active High

• Select jumper for signal differentials.

• Terminals for external drive enable push button.
