Overview
60W DIN-RAIL SWITCHING POWER SUPPLY
12 Volts @ 5 Amps
Specifications:
- Universal AC input range
- Protections: Short-circuit, Overload, Overvoltage
- 100% Full load burn-in test
- Soft-start circuit, limiting AC surge current
- Input Voltage: 85-264VAC @ 47-63Hz, or 120-370VDC
- Input Current @ Full load: 1.8A(115V) / 1.0A(230V)
- Size: 3.9" x 1.6" x 3.5"
- Weight: 0.7 lbs.
- 3-year warranty
| Specification |
Value |
| Primary Output Voltage (VDC) |
12 |
| Output Current (A) |
5 |
| Maximum Output Power (W) |
60 |
| Family |
MDR-60 |
| Input Voltage (VAC) |
85 to 264 |
| Input Frequency |
47 to 63 |
| Maximum Input Current (A) |
1.8 |
| Output Connector Type |
Screw Terminal |
| Efficiency (%) |
86 |
| Operating Temperature-Min (Cel) |
-20 |
| Operating Temperature-Max (Cel) |
70 |
| Length (inch) |
1.57 |
| Width (inch) |
3.54 |
| Height (inch) |
3.94 |
| Agency Approvals |
UL/CUL/TUV/CB/CE |
| Color |
White |
| Style |
DIN |
