SSR25A- Solid State Relay
| Rated Load Current |
25 Ampers
|
|
Input Data
|
|
| Operating Voltage |
3~32VDC
|
| Min. ON/OFF Voltage |
ON 2.4V , OFF 1.0V
|
| Trigger Current |
7.5mA / 12V
|
| Control Method |
Zero Cross Trigger
|
|
Output Data
|
|
| Operating Voltage |
24~380VAC
|
| Min. Block Voltage |
600VAC (Repetive)
|
| Voltage Drop |
1.6V / 25°C
|
| Max. One Cycle Surge |
275A
|
| Leakage Current |
3.0mA
|
| Response Time |
ON 10ms , OFF 10ms
|
|
General Data
|
|
| Dielectric Strength |
Over 2.5KVAC / 1min.
|
| Isolation Strength |
Over 50M? / 500VDC
|
| Operating Temperature |
-20°C ~ + 80�C
|
| Housing Material |
Intensive ABS
|
| Weight |
Appr. 105g
|
Size (Approx.): 6.2 x 4.5 x 2.3cm / 2.44" x 1.77" x 0.9" (L * W * T)
