C78 - RJ45 CONNECTION BOARD

https://www.cnc4pc.com/web/image/product.template/1041/image_1920?unique=4657cac

OVERVIEW

This shield board is used for connection C76 Rev.4 onwards, and C82 Rev.5 onwards. It has
an encoder, limits, port_1 input, signal TTL or Open Collector port_2 output, and connection for axes.

FEATURES

  • RJ45 connector for Axes.

  • RJ45 connector for the encoder.

  • RJ45 connector for limit.

  • RJ45 connector for input port_2.

  • Select jumper.

  • Input terminal optoisolated.

  • Compatibility with C48 Rev 3.5 onwards-EXT_E-STOP

$ 17.28 17.28 USD $ 17.28

Not Available For Sale

    This combination does not exist.

    Contact Us
    OVERVIEW

    This shield board is used for connection C76 Rev.4 onwards, and C82 Rev.5 onwards. It has

    an encoder, limits, port_1 input, signal TTL or Open Collector port_2 output, and connection for axes.

    FEATURES
    • RJ45 connector for Axes.
    • RJ45 connector for the encoder.
    • RJ45 connector for limit.
    • RJ45 connector for input port_2.
    • Select jumper.
    • Input terminal optoisolated.
    • Compatibility with C48 Rev 3.5 onwards-EXT_E-STOP
