C34GV - Connector Board for GEMINI GV Driver

 OVERVIEW

This interfaces board is used for the connection between  C82, C76, C86ACORN, C86MASSO, and the GEMINI GV Series

FEATURES

• CONN MDR PLUG 50 POS RA GOLD connector for Connection of Driver.
• RJ45 Connector for Axis.
• Select Jumper for Hard Enable or Soft Enable.
• Select Jumper for signals Differentials or Step & Direction
• Terminals for external power supply 5VDC
• Encoder output
