OVERVIEW
This interfaces board is used for the connection between C82, C76, C86ACORN, C86MASSO, and the MITSUBISHI MELSERVO-J3 Series 2.0
FEATURES
- CONN PLUG 50 POS connectors for the Connection of Driver.
- RJ45 Connector for Axis.
- Select Jumper for Hard Enable or Soft Enable.
- Select Jumper for signals Differentials or Step & Direction.
- Terminals for external power supply 24VDC.
- Encoder output
